Automatic Screw Feeding System Double Platform Robotic Screwdriver
Machine
Automatic Screwdriver Machine Features:
1.With intelligent detection function, can automatically detect
leakage lock, lock, slide tooth, double Y design, and able to work
alternately
2.Strong flexibility, the standard universal fixture applicable
model of screw lock.
3.Strong commonality, replace the screw conveyor modules can be
adapted to M1.0 - M4.0 screw lock.
4.Equipment for small, save space, reduce the plant resources. Easy
to put into the production line, and before the standard after the
function.
5.Double Y design, alternating operation, maximize production
efficiency, production of profit maximization, the lowest cost of
production.
6.Application: Especially suitable for all kinds of screw lock pay
of consumer electronics, such as calculators, navigation, audio,
camera, laptop, tablet PC, learning machine, small home appliance,
etc.
Automatic Screwdriver Machine Specifications:
| Working Range | 500(X)*300(Y1)*300(Y2)*100(Z)mm |
| Drive mode | 3 axis driver |
| Position Accuracy | ±0.02mm |
| Control System | PLC + TP |
| Screw Feeding | absorption type |
| Operation Method | by Programming |
| Program Memory | 999 groups |
| Voltage | 110-220VAC,50HZ |
| Air Pressure | 4-5kg/cm2 |
| Machine Size | 620*600*720mm |
| Machine Weight | 90kgs |
Automatic Screwdriver Machine Fixtures:
Automatic Screwdriver Machine Application Screws:
Automatic Screwdriver Machine Packaging Details:
1. Fix the machine base on the wooden base by screws
2. Vacuum
3. Pack into wooden case
Delivery Terms:
1. Ex-work/FOB/CIF/DDU, up to clients
2. Production leadtime: 7-15 days to customized make fixture and
test it with the punching machine
Our Service:
1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality
problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation
and training.
5. Solid packaging to prevent damage from transportation.
