    SMT 15W UV PCB Laser Cutting Machine 355nm 40mmх40mm

    Ask Lasest Price
    Brand Name : Winsmart
    Model Number : SMTL600
    Certification : CE
    Price : USD1-150K/set
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100 sets per month
    Delivery Time : 5-30 days
    • Product Details
    • Company Profile

    SMT 15W UV PCB Laser Cutting Machine 355nm 40mmх40mm

    355nm 15W UV PCB Laser Cutting Machine SMT Machine Manufacturers


    PCB depaneling and singulation laser system are gaining popularity-especially as circuit board complexity and component ratios continue to rise.

    Microelectronics and medical device manufacturers reuire close tolerances and minimal debris-this is where laser technology shines.


    PCB Laser Cutting Machine SMT Machine Introduction:

    Compared with the quality problem of traditional manual folding, the emergence of PCB laser cutting machine makes up for this disadvantage. PCB depaneling machine has obvious advantages. PCB laser cutting machine has high work efficiency in production. PCB depaneling machine is very safe when working. Any enterprise should pay attention to the production safety of products in addition to the quality of products, This process has been mandatory by European and American customers as early as 2004.


    PCB Laser Cutting Machine SMT Machine Specification:

    LaserQ-Switched diode-pumped all solid-state UV laser
    Laser Wavelength355nm
    Laser SourceOptowave UV 15W@30KHz
    Positioning Precision of Worktable of Linear Motor±2μm
    Repetition Precision of Worktable of Linear Motor±1μm
    Effective Working Field600mmx600mm(Customizable)
    Scanning Speed2500mm/s (max)
    Working field40mmх40mm

    Machine Advantages:

    1. No mechanical stress

    2. Lower tooling costs

    3. Higher quality of cuts

    4. No consumables

    5. Design versatility-simple software changes enable application changes

    6. Works with any surface-Teflon, ceramic, aluminum, brass and copper

    7. Fiducial recognition achieves precise, clean cuts


    PCB Laser Cutting Machine SMT Machine Applications:
