Adjustable Cutting Force Inline V-Cut PCB Separator With CE
Approval For PCBs
Product Description:
Product Overview: Automatic PCB Separator
Introduction
The V Cut PCB Depaneling Machine, also known as V-groove PCB
Separator, is a cutting-edge device designed to meet the needs of
PCB manufacturers. It is an essential tool for separating printed
circuit boards (PCBs) from a production panel. With its advanced
features and high cutting capacity, this machine is ideal for
processing MCPCB and FR4 materials.
Minimize Speed
The V Cut PCB Depaneling Machine is equipped with a high-speed
motor that allows for a minimize speed of 0-400mm/s. This ensures
efficient and precise cutting, making it ideal for high-volume
production.
Cutting Capacity
This machine has a cutting capacity of 400x400mm, making it
suitable for various sizes of PCBs. It can handle both small and
large panels, providing flexibility for different production needs.
Cutting Force
The cutting force of the V Cut PCB Depaneling Machine is
adjustable, allowing for customization based on the type and
thickness of the PCB material. This feature ensures clean and
accurate cuts without damaging the components on the board.
Device Name
The V Cut PCB Depaneling Machine is also known as an Automatic PCB
Separator. This name emphasizes its automated functionality, making
it a time-saving and efficient tool for PCB separation.
PCB Material
This machine is specifically designed for processing MCPCB and FR4
materials, which are commonly used in PCB manufacturing. It can
handle these materials with ease, ensuring high-quality and precise
cuts.
Conclusion
In summary, the V Cut PCB Depaneling Machine is a versatile and
high-performance device that is essential for PCB manufacturers.
With its advanced features such as high minimize speed, adjustable
cutting force, and compatibility with MCPCB and FR4 materials, it
provides efficient and accurate PCB separation, making it a
valuable asset for any production line.
Features:
- Product Name: V Cut PCB Depaneling Machine
- Blade Type: Saw Blade / Routing Bit
- Pcb Dimension: 250x200mm(standard)
- Cutting Capacity: 400x400mm
- Ce Approval: Yes
- Device Name: Automatic PCB Separator
- V-groove PCB Separator
- Inline V-cut PCB Depanelizer
- Inline PCB Depaneling Machine
- High Precision PCB Separator
Technical Parameters:
| Model | SMTID3 |
| Working area | 250x200mm, 0-80mm(Z) |
| CCD | 540 |
| Spindle | Optional SycoTec and China Brand |
| Screw rod, guide rail, module | China Brand |
| Servo Motor | Panasonic |
| Electrostatic eliminator | ADK-801ADK-801 |
| PC | Industrial Grade |
| Motion control card | PI9074 |
| monitor | 17 inch |
| Operating system | Windows 10 |
| Spindle speed | 40000-60000RPM |
| XYZ drive speed | XY.800mm/s, Z.300mm/s |
| Cutting speed | 0-80mm/s |
| Cutting accuracy | ±0.05mm |
| Overall power | 5KW |
| Working platform | Rotating tray can cut in two directions |
| Spindle cooling system | Air cooling |
| Vacuum cleaner power | 3.5kw 380V,3-Phase(optional top and bottom vacuum cleaning) |
| Air pressure | 0.5-0.7MPa |
| Noise control | <80 dB |
| Safety device | Safety door and sensor |
| Operation mode | Inline |
| PCB Loading | Adjustable feeding conveyor |
| Automatic fault detection and maintenance mode | Self diagnosis function, real-time error information display and
intuitively query the status of each IO port for troubleshooting |
| Technical support and training | Provide equipment operation, programming, hardware maintenance and
training services |
| Vision system | CCD visual positioning correction system |
| Adjustable height | 50-70mm |
| Warning light | Tricolor lamp |
| Working range protective cover | Blind protection mode of hexahedral door |
| Dimension | 1000(L)x1010(W)x1860(H)mm |
| Weight | About 1000kgs |
Applications:
Winsmart SMTID3 V Cut PCB Depaneling Machine
The Winsmart SMTID3 V Cut PCB Depaneling Machine is a cutting-edge
product designed and manufactured in China. This innovative machine
is specifically designed for efficient and precise separation of
printed circuit boards, making it an essential tool for electronic
manufacturing companies.
Product Features
- Brand Name: Winsmart
- Model Number: SMTID3
- Place of Origin: China
- Pcb Connection: Milling Bridge and V-cut
- Device Name: Automatic PCB Separator
- Cutting Capacity: 400x400mm
- Condition: New
- Advantage: Full Automatic
The Winsmart SMTID3 V Cut PCB Depaneling Machine is equipped with
the latest technology and advanced features, making it a top choice
for electronic manufacturers. It is designed to provide superior
performance and high precision in PCB separation, and is suitable
for a wide range of applications.
Product Applications
The Winsmart SMTID3 V Cut PCB Depaneling Machine is suitable for
the following applications and scenarios:
- Inline PCB Depanel: This machine is ideal for inline PCB depaneling, providing a
seamless and efficient process for separating PCBs.
- Inline PCB Depaneling Machine: The Winsmart SMTID3 is a highly efficient and reliable inline PCB
depaneling machine, designed to meet the demands of high-volume
production.
- Inline V-cut PCB Depanelizer: With its advanced V-cut technology, this machine is perfect for
inline V-cut PCB depanelization, ensuring clean and accurate cuts
every time.
- Automatic PCB Separator: The Winsmart SMTID3 is a fully automatic PCB separator,
eliminating the need for manual labor and reducing production time
and costs.
- PCB Cutting Machine: This machine is specifically designed for PCB cutting, providing a
fast and efficient solution for electronic manufacturers.
With its versatile applications and advanced features, the Winsmart
SMTID3 V Cut PCB Depaneling Machine is a must-have for any
electronic manufacturing company looking to improve their
production process and achieve high-quality results.
